W-LIGHT ROOFING
W-LIGHT ROOFING
Corrugated roofing sheets are crafted from cellulose that is impregnated with bitumen and polymer resins, and reinforced with a mineral filler. The cellulose layer serves to maintain the sheet's structural shape, while the bitumen and resins deliver excellent waterproofing capabilities. The sheets feature a wavy design, which adds extra rigidity and helps prevent water from seeping through the joints during rainfall. For a decorative finish, mineral pigments are incorporated into the material, providing both durability and aesthetic appeal.
all
Grey
Red
Brown
Green
| CHARACTERISTICS | TEST METHOD | PERFORMANCE |
|---|---|---|
| Dimensions (Length x Width), mm | - | 2000 (±20) x 950 (±20) |
| Thickness, mm | - | 3 (±0.3) |
| Indicative weight of a sheet, kg | - | 6.51 (±10%) |
| Weight per m2. kg | - | 3.4 (±10%) |
| Density, g/cm3 | - | 0.87 - 1.15 |
| Corrugations per sheet, pcs | - | 10 |
| Profile (Pitch x Height), mm | - | 95 x 38 ± 2.3 |
| Water absorption within 24 hours, % by weight | - | ≤1.5 |
| Bending under downward load at t=25ᵅC N/m2 | EN 534:2010 | ≥ 1400 |
| Tensile strength, MPa | EN 534:2010 | 6.5 |
| Impact resistance, mm | EN 534:2010 | 400 |
| Tearing strength N | EN 534:2010 | >200 |
| Installation method | - | nailing |
